Vacuum tube lifting machine TS operating instructions

Built in release valve, can quickly release vacuum
Designed according to ergonomic principles, lightweight and easy to operate
Increase travel distance -1700mm/2600mm

One handed operation control instructions: Use the index finger to control the lifting handle to achieve the size of the vacuum valve opening and lift the lifting tube;
a、 Empty load balance regulating valve: Rotate clockwise to raise the lifting pipe; Rotate counterclockwise to lower the lifting tube; After confirming the height, each time the power is turned on, the lifting tube will automatically rise to this position to meet the comfortable operating position of the operator;
b、 Descent control: Hold the handle with your palm and press the lifting handle with your index finger. The speed of the press determines the speed and corresponding position of the lifting tube descent
c、 Rising control: When descending to the position where the suction feet is attached to the workpiece, the index finger releases the lifting tube to rise, and the speed of release determines the speed and corresponding position of the lifting tube rising
d、 Release control: After using the descent control or ascent control to a certain position, press the lifting handle to the bottom with the index finger, and push the quick release valve with the thumb to release the workpiece
